r-bot+h-bot

dense storage system

R-bot+H-bot dense storage system is suitable for the whole pallet in/out or a small amount of picking in/out scenarios. Compared with stacker cranes AS/RS, the storage density and comprehensive efficiency are greatly improved, with the advantages of high efficiency, high density, high flexibility, quick delivery and so on, which is the best choice for the customers in pursuit of the maximum storage density and improvement of the space utilization rate.

download pdf

The Advantages of R-bot+H-bot dense storage system

R-bot dense storage system, using R-bot four-way shuttle and H-bot high-speed elevator horizontal and vertical combination of operations, combined with PTP smart warehousing software, to achieve the maximum degree of dense storage, space utilization rate is very high. The system is not restricted by fixed routes and can reach any position in the space. It can also flexibly increase or decrease the number of four-way shuttles according to the business requirements, and can be flexibly matched with conveyor lines and AMR to complete the rapid in and out of the warehouse.

High Efficiency

Comprehensive efficiency increase of 2-3 times compared to traditional warehouses, and 15%-20% compared to ordinary automated three-dimensional warehouses (stacker cranes AS/RS)

High Density

The storage density is 4-6 times higher than in traditional warehouses and 30-100% higher than in ordinary automated three-dimensional warehouses (stacker cranes AS/RS)

High Flexibility

Suitable for new or renovated warehousing scenes, suitable for multiple pillars, cross-floor, irregular warehouse types, according to the business needs of the change in the number of flexible increase or decrease in the number of equipment

Quick Delivery

Reduction of delivery times by more than 40 % in comparison to ordinary automated three-dimensional warehouses (stacker cranes AS/RS), resulting in high quality deliveries

In Action

Receiving Process

STEP 1

The palletised materials are sent to the inbound port by forklift, and the materials are requested to the WMS system for warehousing after the materials have passed the shape inspection, code scanning and other equipment to check the information and inspection;

STEP 2

Materials that meet the qualifications for inbound delivery are sent by the conveyor system to the elevator, which then transports the materials to the pick-up conveyor line on the specified floor to wait for the four-way shuttle to pick up the materials;

STEP 3

The four-way shuttle travels from the standby point to the connecting conveyor line, jacks up and transports the materials to the designated position, and feeds back to the upper level information system, and the backend system updates the inventory information in real time.

Dispatch Process

STEP 1

According to the order or warehouse plan, WMS sends out the warehouse task instruction, and WCS system schedules the four-way shuttle;

STEP 2

The four-way shuttle receives the order to leave the warehouse and drives from the standby point to the designated storage position to lift the goods out and place them at the front end of the elevator to connect the conveyor line;

STEP 3

The goods enter the elevator through the conveyor, and the elevating and conveying equipment automatically transports the materials to the outbound port, and waits for the forklift to transport the materials to the designated place for the whole pallet to be taken out of the warehouse;

STEP 4

After the forklift picks up the material from the conveyor line at the outbound port, the background system updates the inventory information in real time.

.

Features and Benefits

Temperature Environment

R-bot covers -25℃~45℃ temperature environment, suitable for multiple pallet sizes.

Accurate positioning

Positioning accuracy ±1mm, breakthrough cargo space spacing,RFID + magnetic induction + encoder positioning, high robustness.

Intelligent Charging Piles

Intelligent charging piles in the storage position, real-time monitoring of charging and safety protection.

Multi-type Equipment

Multi-type equipment and multi-vehicle cross-layer scheduling, task balanced matching, over 100 R-bot cluster scheduling.

Quick Outbound and Inbound

Can be used with AMR quick outbound and inbound, can also or with mechanical arm to piece picking.

OCR Industrial Scanning Camera

Can be used with OCR industrial scanning camera, accurate recognition, improve the accuracy of the inbound and outbound warehouse.

Data Simulation

Net size of warehouse: L60m*W20m*H30m
Product portfolio R-bot*6 H-bot*2
No. of storage positions 2984
Applicable SKUs ≤10000
Efficiency of in/out storage ≥100 pallets/hour
Investment amount USD 600,000+

Connect with our experts to receive customized robotics solutions

Applications

Scenarios

N.H. of warehouse ≤30m

No. of SKUs: lesser

Storage Density: High

In/Out Storage Efficiency: High

Picking efficiency: Average

Industries

Food

Manufacture

Cold Chain

Energy

3PL

Building Materials

Chemical

Household

3PL

Chemical

Building Materials

Home Furnishings

Cold Chain

Food

Manufacture

Energy

Case Studies

Jointown Pharmaceutical

Pain points: Under new requirements, the company set an overall processing volume of 10,000 pieces/hour with 99.9% accuracy.

Solution: Picking robots transport goods directly to the platform for unmanned unloading. User friendly interface providing multiple data gathering, reducing operation risks and increasing transportation safety.

1/3increased 1400per hour

storage capacity outbound
